CosTaperedWin
Advanced Analysis Library Only
AnalysisLibErrType CosTaperedWin (double arrayX[], ssize_t numberOfElements);
Purpose
 |
Note This function has been superseded by CosTaperedWinEx. |
Applies a cosine-tapered window to the input signal. If Y represents the output sequence, CosTaperedWin obtains the elements of Y from the following formula:
| where |  |
| n is the number of elements in arrayX |
Parameters
| Input | ||
| Name | Type | Description |
| numberOfElements | ssize_t | Number of elements in x. |
| Output | ||
| Name | Type | Description |
| arrayX | double [] | On input, the input signal. On output, this parameter returns the input signal with a cosine-tapered window applied. |
Return Value
| Name | Type | Description |
| status | AnalysisLibErrType | A value that specifies the type of error that occurred. Refer to analysis.h for definitions of these constants. |
Additional Information
Library: Advanced Analysis Library
Include file: analysis.h
LabWindows/CVI compatibility: LabWindows/CVI 3.1 and later
